L532 - IGBT phaseleg in ISOPLUS i4-PAC

L532 Description

FII 30-06D IGBT phaseleg in ISOPLUS i4-PACTM IC25 = 30 A = 600 V VCES VCE(sat) typ.= 1.9 V 3 5 4 Preliminary data 1 1 2 5 IGBTs Symbol VCES VGE.

L532 Features

* NPT IGBT - low saturation voltage - positive temperature coefficient for easy paralleling - fast switching
* HiPerFREDTM diode - optimized fast and soft reverse recovery - low operating forward voltage - low leakage current
* ISOPLUS i4-PACTM package - isolated back surface

L532 Applications

* single phaseleg - buck-boost chopper
* H bridge - power supplies - induction heating - four quadrant DC drives - controlled rectifier
* three phase bridge - AC drives - controlled rectifier Symbol Conditions Characteristic Values (TVJ = 25°C, unless otherwise specified)

📥 Download Datasheet

Preview of L532 PDF
