IRFP4905 - P-Channel MOSFET

INCHANGE

📥 Download Datasheet

IRFP4905 Datasheet Preview — Preview of IRFP4905 PDF

Datasheet Details

Part number	IRFP4905
Manufacturer	INCHANGE
File Size	248.70 KB
Description	P-Channel MOSFET
Datasheet	IRFP4905-INCHANGE.pdf

IRFP4905 Product details

Description

Designed for use in switch mode power supplies and general purpose applications.ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VDSS Drain-Source Voltage -55 V VGS Gate-Source Voltage-Continuous ±20 V ID Drain Current-Continuous -70 A IDM Drain Current-Single Pluse -280 A PD Total Dissipation @TC=25℃ 170 W TJ Max.Operating Junction Temperature -55~150 ℃ Tstg Storage Temperature -55~150 ℃ THERMAL CHARACTERISTICS SYMBOL PARAMETER Rth j-c Thermal

Features

Drain Current.
ID= -70A@ TC=25℃.
Drain Source Voltage- : VDSS= -55V(Min).
Static Drain-Source On-Resistance : RDS(on) = 20mΩ(Max).
100% avalanche tested.
Minimum Lot-to-Lot variations for robust device performance and reliable operation.
