CDP680SG2 - CMOS High-Performance Silicon-Gate 8-Bit Microcomputer

GE

The CDP680SG2 by GE is a CMOS High-Performance Silicon-Gate 8-Bit Microcomputer. Below is the official datasheet preview.

📥 Download Datasheet

CDP680SG2 CMOS High-Performance Silicon-Gate 8-Bit Microcomputer by GE - Datasheet Preview — Official preview page of the CDP680SG2 CMOS High-Performance Silicon-Gate 8-Bit Microcomputer datasheet (GE).

Datasheet Details

Part number	CDP680SG2
Manufacturer	GE
File Size	1.42 MB
Description	CMOS High-Performance Silicon-Gate 8-Bit Microcomputer
Datasheet	CDP680SG2-GE.pdf
Additional preview pages of the CDP680SG2 datasheet.

CDP680SG2 Product details

Features

Typical full speed operating power of 12 mWat5 V.
Typical WAIT mode power of 4 mW.
Typical STOP mode power of 5 /JW.
Fully static operation.
112 bytes of on-chip RAM.
2106 bytes 01 on-chip ROM.
32 bidirectionalI/O lines.
High current drive'.
Internal B-bit timer with soltware programmable 7-bit prescaler.
External timer input.
External and timer interrupts.
Self-check mode.
Mas.
