The MBL80186 is NMOS HIGH-INTEGRATION 16-BIT MICROPROCESSOR designed by Fujitsu.
| Part number | MBL80186 |
|---|---|
| Manufacturer | Fujitsu |
| File Size | 3.80 MB |
| Description | NMOS HIGH-INTEGRATION 16-BIT MICROPROCESSOR |
| Datasheet |
MBL80186-Fujitsu.pdf
|
|
|
|
Table 1 - PIN DESCRIPTION Symbol Vee, Vee Vss , Vss RESET Pin No.9,43 26,60 57 Xl,X2 59,58 ClKOUT 56 RES 24 TEST 47 TMR IN 0, 20 TMR IN 1 21 TMR OUTO, 22 TMROUT 1 23 DROO, 18 DROl 19 NMI 46 INTO,INT1, INT2/1 NTAO, INT3/INTAl 45,44 42 41 Type I I 0 I o I I 0 0 I I I I I/O I/O Name and Function System Power: +5 V power supply.System Ground.Reset Output indicates that the MB l 80186 CPU is being reset, and can be used as a system reset.It is active HIGH, synchronized
