Description
Pin No.
Power supply input for charge pump
4
VCC
Power supply voltage input
Charge pump output
5
DO
O The phase characteristics can be inversed depending upon the FC input.6
GND
Ground
Phase comparator output
7
LD
O This pin outputs high when the phase is locked.While the phase difference of fr and fp exists,
Features
- High operating frequency: fIN MAX=520MHz (VIN MIN=0.20VP-P).
- On-chip prescaler.
- Low power supply voltage: 2.7V to 5.5V (3.0V typ).
- Low power supply consumption: 30mW (3.0V, 520MHz operation).
- Serial input 18-bit programmable divider consisting of:.
- Binary 7-bit swallow counter (Divide ratio: 0 to 127).
- Binary 11-bit programmable counter (Divide ratio: 16 to 2047).
- Serial input 15-bit programmable reference divider consisting.
