LM2902AM, LM2902 - Quad Operational Amplifier

Fairchild Semiconductor

📥 Download Datasheet

LM2902AM Datasheet Preview — This datasheet PDF includes multiple part numbers: LM2902AM, LM2902. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	LM2902AM, LM2902
Manufacturer	Fairchild Semiconductor
File Size	Direct Link
Description	Quad Operational Amplifier
Datasheet	LM2902_FairchildSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: LM2902AM, LM2902. Please refer to the document for exact specifications by model.

LM2902AM Product details

Description

The LM324/LM324A, LM2902/LM2902A consist of four independent, high gain, internally frequency compensated operational amplifiers which were designed specifically to operate from a single power supply over a wide voltage range.

Features

Internally Frequency Compensated for Unity Gain.
Large DC Voltage Gain: 100dB.
Wide Power Supply Range: LM324/LM324A : 3V~32V (or ±1.5 ~ 16V) LM2902/LM2902A: 3V~26V (or ±1.5V ~ 13V).
Input Common Mode Voltage Range Includes Ground.
Large Output Voltage Swing: 0V to VCC -1.5V.
Power Drain Suitable for Battery Operation.
