FDMF5826DC - Smart Power Stage (SPS) Module

Fairchild Semiconductor

Datasheet Details

Part number	FDMF5826DC
Manufacturer	Fairchild Semiconductor
File Size	1.27 MB
Description	Smart Power Stage (SPS) Module
Datasheet	FDMF5826DC-FairchildSemiconductor.pdf

Ultra-Compact 5 mm x 5 mm PQFN Copper-Clip Package with Flip Chip Low-Side MOSFET and Dual Cool Architecture.
High Current Handling: 60 A.
3-State 5 V PWM Input Gate Driver.
Dynamic Resistance Mode for Low-Side Drive (LDRV) Slows Low-Side MOSFET during Negative Inductor Current Switching.
Auto DCM (Low-Side Gate Turn Off) Using ZCD# Input.
Thermal Monitor for Module Temperature Reporting.
HS-Short Detect Fault# / Shutdown.
Dual Mode Enable / Fault# Pin.
