FAN6920MR - Integrated Critical-Mode PFC and Quasi-Resonant Current-Mode PWM Controller

Fairchild Semiconductor

The FAN6920MR by Fairchild Semiconductor is a Integrated Critical-Mode PFC and Quasi-Resonant Current-Mode PWM Controller. Below is the official datasheet preview.

📥 Download Datasheet

FAN6920MR Integrated Critical-Mode PFC and Quasi-Resonant Current-Mode PWM Controller by Fairchild Semiconductor - Datasheet Preview — Official preview page of the **FAN6920MR** Integrated Critical-Mode PFC and Quasi-Resonant Current-Mode PWM Controller datasheet (Fairchild Semiconductor).

Datasheet Details

Part number	FAN6920MR
Manufacturer	Fairchild Semiconductor
File Size	1.09 MB
Description	Integrated Critical-Mode PFC and Quasi-Resonant Current-Mode PWM Controller
Datasheet	FAN6920MR_FairchildSemiconductor.pdf
Additional preview pages of the FAN6920MR datasheet.

FAN6920MR Product details

Description

The highly integrated FAN6920MR combines Power Factor Correction (PFC) controller and quasi-resonant PWM controller.

Features

Integrated PFC and Flyback Controller Critical-Mode PFC Controller Zero-Current Detection for PFC Stage Quasi-Resonant Operation for PWM Stage Internal Minimum 5µs tOFF for QR PWM Stage Internal 5ms Soft-Start for PWM Brownout Protection High / Low Line Over-Power Compensation Auto-Recovery Over-Current Protection Auto-Recovery Open-Loop Protection Externally Auto-Recovery Triggering (RT Pin) Adjustable Over-Temp.
