CNY171M Datasheet (Fairchild Semiconductor) - Phototransistor Optocouplers

CNY171M, Phototransistor Optocouplers

The CNY17XM, CNY17FXM, and MOC8106M devices consist of a gallium arsenide infrared emitting diode coupled with an NPN phototransistor in a dual in-line package.

Package Outlines Figure 1.

Package Outlines Schematics ANODE 1 6 NC ANODE 1 6 BASE CATHODE 2 5 COLLECTOR CATHODE 2 5 COLLECTOR NC

CNY171M Features

* High BVCEO: 70 V Minimum (CNY17XM, CNY17FXM, MOC8106M)

* Closely Matched Current Transfer Ratio (CTR) Minimizes Unit-to-Unit Variation

* Current Transfer Ratio In Select Groups

* Very Low Coupled Capacitance Along With No Chip-to-Pin 6 Base Connection for Minimum Noise Susceptabili
