ALD18F48-6L, ALD-18F DC-DC / Intermediate Bus Converter

ALD18F48-6L Description

Astec Industry Standard 25 Amps ALD25 Total Power: Input Voltages: No.of Outputs: 60W 48 Single Electrical Specs Input Input Range Input Surge Ef.

ALD18F48-6L Features

* High Efficiency -40°C to +85°C Ambient Air Operation 1.30” x 0.9" x 0.35" TH or SMT package High capacitive load limit on start-up Industry standard feature sets: UVLO, OVP, OCP, OTP, On/Off Enable, Remote Sense, Output Trim Basic Insulation Regulati

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: ALD18F48-6L, ALD-18F. Please refer to the document for exact specifications by model.
datasheet Preview Page 2

Datasheet Details

Part number
ALD18F48-6L, ALD-18F
Manufacturer
Emerson
File Size
324.37 KB
Datasheet
ALD-18F-48.pdf
Description
DC-DC / Intermediate Bus Converter
Note
This datasheet PDF includes multiple part numbers: ALD18F48-6L, ALD-18F.
Please refer to the document for exact specifications by model.
