EMP8042 - Low-Dropout Linear Regulator

Elite Semiconductor

Datasheet Details

Part number	EMP8042
Manufacturer	Elite Semiconductor
File Size	757.86 KB
Description	Low-Dropout Linear Regulator
Datasheet	EMP8042-EliteSemiconductor.pdf

The EMP8042 is a high voltage, low quiescent current, low dropout regulator with 150mA output driving capacity.

 150mA output current driving capacity  780mV typical dropout at Io=150mA  13µ A typical quiescent current  1µA typical shutdown mode  Up to 20V input range  Stable with small ceramic output capacitors (1µ F)  Over temperature and over current protection VIN 1uF EMP8042 (SOT-23-5) 1 VIN 5 VOUT 3 EN GND 2 NC 4 Fixed Output EMP8042 (SOT-23-5) VOUT VIN 1 VIN 1uF 1uF 3 EN GND 2 VOUT  1   R1 R2    Vref 5 VOUT R1 1uF ADJ 4 R2 VOUT Adjustable Output Elite Se.
