EMA1201 - 2W Stereo Audio Power Amplifier

Name: EMA1201
SKU: EMA1201-826690

Elite Semiconductor

📥 Download Datasheet

EMA1201 Datasheet Preview — Preview of EMA1201 PDF

Datasheet Details

Part number	EMA1201
Manufacturer	Elite Semiconductor
File Size	243.27 KB
Description	2W Stereo Audio Power Amplifier
Datasheet	EMA1201-EliteSemiconductor.pdf

EMA1201 Product details

Description

The EMA1201 is a stereo bridged audio power amplifier capable of delivering 1.2W of continuous average power into a 8Ω load or 1.7W into 4Ω with less than 1% THD when powered by a 5V power supply.

Features

a low-power consumption shutdown mode, and an internal thermal shutdown protection mechanism. Advanced pop & click circuitry is built in to eliminate noises that would otherwise occur during turn-on and turn-off transitions. The EMA1201 is unity-gain stable and can be configured by external gain-setting resistors. EMP products are Pb-free and RoHS compliant. EMA1201 2W Stereo Audio Power Amplifier with Shutdown Mode ．BTL mode PO at THD+N=1%, f=1kHz, VDD =5V 1.7 W (typ) into 4Ω 1.2 W (typ) into.
