SC-A147A - CRYSTAL CLOCK OSCILLATORS

SC-A147A Description

CRYSTAL CLOCK OSCILLATORS LVCMOS Data Sheet 0149A Rev.B SC-A1470 Series PRELIMINARY .
The SC-A1470 Series of quartz crystal oscillators provide enable/disable 3-state LVCMOS compatible signals for bus connected systems.

SC-A147A Features

* Wide freqency range: 4.0MHz to 20.0MHz
* User specified tolerance ±100ppm
* Will withstand vapor phase temperatures of 253°C for 4 minutes maximum
* Space-saving alternative to discrete component oscillators
* High shock resistance, to 1000g
* Low Ji

📥 Download Datasheet

Preview of SC-A147A PDF
datasheet Preview Page 2

Datasheet Details

Part number
SC-A147A
Manufacturer
ETC
File Size
168.29 KB
Datasheet
SC-A147A_ETC.pdf
Description
CRYSTAL CLOCK OSCILLATORS
