B82721xxxx, B82721A2401N21 EMC / Filters / Suppression

B82721xxxx Description

EMC, FILTERS & SUPPRESSION MURATA type PLA10 CHOKES, Common Mode EMIFIL® A range of uncased vertical core, compact common mode chokes.Suitable for .

B82721xxxx Applications

* such as switch mode power supplies. Specification Voltage rating Withstand voltage Insulation resistance Operating temperature range Current Rating (Aac) 1.0 1.2 1.5 2.1 2.6 3.6 Inductance min. (µH) 370 290 220 160 110 70 w w 300V 2000V 100MΩ min. -25°C to +120°C w t a . D S a e h N N N

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: B82721xxxx, B82721A2401N21. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
B82721xxxx, B82721A2401N21
Manufacturer
EPCOS
File Size
208.23 KB
Datasheet
B82721A2401N21_EPCOS.pdf
Description
EMC / Filters / Suppression
Note
This datasheet PDF includes multiple part numbers: B82721xxxx, B82721A2401N21.
Please refer to the document for exact specifications by model.
