BAV116S92 - SURFACE MOUNT LOW LEAKAGE DIODE

Name: BAV116S92
SKU: BAV116S92-1504617

Diodes

📥 Download Datasheet

BAV116S92 Datasheet Preview — Preview of BAV116S92 PDF

Datasheet Details

Part number	BAV116S92
Manufacturer	DIODES
File Size	469.93 KB
Description	SURFACE MOUNT LOW LEAKAGE DIODE
Datasheet	BAV116S92-Diodes.pdf

BAV116S92 Product details

Description

and Applications The BAV116S92 is a 85V, 5.0nA and 3.0µs switching diode that is optimized for low leakage current.It is ideally suited for use in applications such as the following: Mobile Portable Electronics Consumer Electronics

Features

Ultra Low Leakage Current (5nA @ VR = 75V).
Ultra-small Surface Mount Package (1.0 x 0.6 x 0.37mm).
Low Capacitance.
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2).
Halogen and Antimony Free. “Green” Device (Notes 3) Mechanical Data.
Case: SOD923.
Case Material: Molded Plastic, "Green" Molding Compound. UL Flammability Classification Rating 94V-0.
Moisture Sensitivity: Level 1 per J-STD-020.
Terminals: Matte Tin Finish Annealed over Alloy 42.
