CDBFR001A - SMD Schottky Barrier Diode

Comchip Technology

Datasheet Details

Part number	CDBFR001A
Manufacturer	Comchip Technology
File Size	79.45 KB
Description	SMD Schottky Barrier Diode
Datasheet	CDBFR001A_ComchipTechnology.pdf

Designed for mounting on small surface. Extremely thin package. Low stored charge. Majority carrier conduction. 0.051(1.30) 0.043(1.10) 1005(2512) 0.102(2.60) 0.095(2.40) Mechanical data Case: 1005(2512) standard package, molded plastic. Terminals: Gold plated, solderable per MIL-STD-750,method 2026. Polarity: Indicated by cathode band. Mounting position: Any Weight: 0.006 gram(approx. ). 0.040(1.00) Typ. 0.020(0.50) Typ. 0.035(0.90) 0.027(0.70) Dimensions in inches and (millimeter) Maximum R.
