PE2333A - P-Channel Enhancement Mode Power MOSFET

ChipSourceTek

📥 Download Datasheet

PE2333A Datasheet Preview — Preview of PE2333A PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	PE2333A
Manufacturer	ChipSourceTek
File Size	786.56 KB
Description	P-Channel Enhancement Mode Power MOSFET
Datasheet	PE2333A-ChipSourceTek.pdf

PE2333A Product details

Description

The PE2333A uses advanced trench technology to provide excellent RDS(ON) and low gate charge.

Features

VDS = -18V, ID = -6A RDS(ON) < 28mΩ @ VGS=-4.5V RDS(ON) < 40mΩ @ VGS=-2.5V Schematic diagram.
High Power and current handing capability.
Lead free product is acquired.
Surface Mount Package.
