AZ7805D, AZ78xx - 3-TERMINAL POSITIVE LINEAR REGULATORS

BCD Semiconductor

AZ7805D Datasheet Preview — This datasheet PDF includes multiple part numbers: AZ7805D, AZ78xx. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	AZ7805D, AZ78xx
Manufacturer	BCD Semiconductor
File Size	167.33 KB
Description	3-TERMINAL POSITIVE LINEAR REGULATORS
Datasheet	AZ78xx_BCDSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: AZ7805D, AZ78xx. Please refer to the document for exact specifications by model.

AZ7805D Product details

Description

The AZ78XX series are monolithic integrated circuits designed as fixed-voltage regulators for a wide variety of applications including local, on-card regulation.

Features

Output Current up to 1.0A Fixed Output Voltages of 5V, 6V, 8V, 9V and 12V Output Voltage Tolerances of 5% over the Full Temperature Range Internal Short Circuit Current-limiting Internal Thermal Overload Protection.

📁 AZ7805D Similar Datasheet
