ATS643LSH - Zero-Speed Differential Gear Tooth Sensor

Allegro MicroSystems

ATS643LSH Datasheet Preview — Preview of ATS643LSH PDF

Datasheet Details

Part number	ATS643LSH
Manufacturer	Allegro MicroSystems
File Size	414.77 KB
Description	Zero-Speed Differential Gear Tooth Sensor
Datasheet	ATS643LSH_AllegroMicroSystems.pdf

ATS643LSH Product details

Description

The ATS643 is an optimized combination of integrated circuit and magnet that provides a manufacturer-friendly solution for true zero-speed digital gear-tooth sensing in two-wire applications.

Features

Fully-optimized differential digital gear tooth sensor Single chip-IC for high reliability Internal current regulator for 2-wire operation Small mechanical size (8 mm diameter x 5.5 mm depth) Switchpoints air gap independent Digital output representing gear profile Precise duty cycle accuracy throughout temperature range.
Large operating air gaps.
