DSS020 - (DSSxxx) Board to Board Interconnections

Product Overview

📥 Download Datasheet

DSS020 (DSSxxx) Board to Board Interconnections by Advanced Interconnections - Datasheet Preview — Datasheet preview – DSS020

Datasheet Details

Part number	DSS020
Manufacturer	Advanced Interconnections
File Size	186.15 KB
Description	(DSSxxx) Board to Board Interconnections
Datasheet	DSS020 Datasheet
Additional preview pages of the DSS020 datasheet.

Product details

Features

Molded Adapter & Socket Adapter & Socket Single Row m o c Board to Board Interconnections ¤ Peel-A-Way Adapter & Socket Adapter & Socket.
Sockets and adapters are designed in mating pairs.
.050” (1.27mm) and .100” (2.54mm) centers spacing row to row.
High reliability screw machine terminals with closed end construction for 100% antiwicking of solder.
For surface mount board to board options consult factory. SDA, NBA, KBA - Male / SDS, KBS - Female Du.
