Description
Applications
The HSMP-389x series is o ptimized for switching applications where low resistance at low current and low capacitance are required.The HSMP-489x series products feature ultra low parasitic inductance.These products are specifically designed for use at frequencies which are much higher than the upper limit for conventional PIN diodes.Pin Connections and Package Marking
16 25
34
Notes: 1. Package marking provides orientation, identification, and date
code.2. See “Electrical Sp
Features
- Unique Configurations in Surface Mount Packages.
- Add Flexibility.
- Save Board Space.
- Reduce Cost.
- Switching.
- Low Capacitance.
- Low Resistance at Low Current.
- Low Failure in Time (FIT) Rate[1].
- Matched Diodes for Consistent Performance.
- Better Thermal Conductivity for Higher Power
Dissipation.
- Lead-free
Note: 1. For more information see the Surface Mount PIN Reliability Data
Sheet. Pa.
