AT42QT1110-AU, AT42QT1110-MU 11-key QTouch Touch Sensor

AT42QT1110-AU Description

Atmel AT42QT1110-MU AT42QT1110-AU 11-key QTouch® Touch Sensor IC .
Table 1-1.

AT42QT1110-AU Features

* DATASHEET
* Sensor Keys:
* Up to 11 QTouch® channels
* Data Acquisition:
* Measurement of keys triggered either by a signal applied to the SYNC pin or at regular intervals timed by the AT42QT1110 internal clock
* Keys measured sequentially for better performance, or in parallel

AT42QT1110-AU Applications

* Consumer and industrial applications, such as TV, media player 9520J
* AT42
* 05/2013 1. Pinout and Schematic 1.1 Pinout Configuration SNS0 SNS10K/SYNC SNS10/DETECT6 RESET CHANGE SNS9K/DETECT5 SNS9/DETECT4 SNS8K/DETECT3 SNS0K SNS1 SNS1K VDD VSS SNS2K SNS2 SNS3 32 31 30 29 28
