ALT1110 - Operational Amplifier

📥 Download Datasheet

ALT1110 Datasheet Preview — Preview of ALT1110 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	ALT1110
Manufacturer	ARTCHIP
File Size	1.70 MB
Description	Operational Amplifier
Datasheet	ALT1110-ARTCHIP.pdf

ALT1110 Product details

Features

Bandwidth.
290 MHz (G = 1,.
3 dB).
110 mA Output Current Drive (Typical).
Wide Supply Range ±5 V to ±15 V.
Supply Current . . . 1.9 mA/Channel.
7.5 nV/√Hz Voltage Noise.
Very Low Distortion.
THD =.
80 dBc (f = 1 MHz, RL = 150 Ω) s Recommended operating conditions Supply voltage, VCC Operating free-air temperature, TA ALT1110 NULL 1 8 NULL IN.
2 7 VCC+ IN + 3 6 OUT CC.
4 5 NC Figure 1.
