HM78L33 - 30V 100mA Low Dropout Linear Regulator

Download the HM78L33 datasheet PDF. This datasheet also covers the HM78L03 variant, as both devices belong to the same 30v 100ma low dropout linear regulator family and are provided as variant models within a single manufacturer datasheet.

Description

The HM78LXX is a fixed voltage (3V/3.3V/5V) threeterminal integrated regulator that can be used in many applications.

Its excellent internal current limit and thermal shutdown characteristics make it especially suitable for overload conditions.

Features

  • ±2% output voltage tolerance.
  • VIN range up to 30V.
  • Maximum output current 100mA.
  • Output transistor safe area protection.
  • Built-in Thermal Protection.
  • Built-in Overcurrent Protection.
