TPS62877-Q1 - Synchronous Step-Down Converter

Download the TPS62877-Q1 datasheet PDF. This datasheet also covers the TPS62874-Q1 variant, as both devices belong to the same synchronous step-down converter family and are provided as variant models within a single manufacturer datasheet.

General Description

The TPS62874-Q1, TPS62875-Q1, TPS62876-Q1 and TPS62877-Q1 are a family of pin-to-pin, 15A, 20A, 25A, and 30A synchronous step-down DC/DC converters with I2C interface and differential remote sense.

All devices offer high efficiency and ease of use.

Key Features

  • AEC-Q100 qualified for automotive.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (TPS62874-Q1-etcTI.pdf) that lists specifications for multiple related part numbers.

Other Datasheets by Texas Instruments

Part Number Description
TPS62870 Synchronous Step-Down Converters
TPS62870-Q1 Synchronous StepDown Converters
TPS62871 Synchronous Step-Down Converters
TPS62871-Q1 Synchronous StepDown Converters
TPS62872 Synchronous Step-Down Converters
TPS62872-Q1 Synchronous StepDown Converters
TPS62873 Synchronous Step-Down Converters
TPS62873-Q1 Synchronous StepDown Converters
TPS62874-Q1 Synchronous Step-Down Converter
TPS62875-Q1 Synchronous Step-Down Converter

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
TPS62874-Q1, TPS62875-Q1, TPS62876-Q1, TPS62877-Q1 SLVSFU1D – APRIL 2023 – REVISED DECEMBER 2024 TPS6287x-Q1 2.7V to 6V Input, 15A, 20A, 25A, and 30A Automotive, Fast Transient, Synchronous Step-Down Converter With I2C Interface 1 Features • AEC-Q100 qualified for automotive applications – Device temperature grade 1: –40°C to 125°C TA – –40°C to 150°C junction temperature range • Functional Safety-Capable – Documentation available to aid functional safety system design • Input voltage range: 2.7V to 6V • Family of pin-to-pin compatible devices: 15A, 20A, 25A, and 30A • Three selectable output voltage ranges from 0.4V to 1.675V – 0.4V to 0.71875V with 1.25mV steps – 0.4V to 1.0375V with 2.5mV steps – 0.4V to 1.675V with 5mV steps • Output voltage accuracy: ±0.
