INA126 - MicroPower Instrumentation Amplifier

General Description

The INA126 and INA2126 (INAx126) are precision instrumentation amplifiers for accurate, low-noise, differential-signal acquisition.

The two-op-amp design provides excellent performance with low quiescent current (175 μA/channel).

Key Features

  • Low quiescent current: 175 μA/channel.
  • Wide supply range: ±1.35 V to ±18 V.
  • Low offset voltage: 250-μV maximum.
  • Low offset drift: 3-μV/°C maximum.
  • Low noise: 35 nV/√Hz.
  • Low input bias current: 25-nA maximum.
  • Temperature range:.
  • 40°C to +85°C.
  • Multiple package options:.
  • Single channel:.
  • INA126P/PA 8-pin PDIP (P).
  • INA126U/UA 8-pin SOIC (D).
  • INA126E/EA 8-pin VSSOP (DGK).
  • Dua.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
INA126 MicroPOWER INSTRUMENTATION AMPLIFIER Burr-Brown Corporation
INA120 INSTRUMENTATION AMPLIFIER Burr-Brown Corporation
INA121 FET-Input/ Low Power INSTRUMENTATION AMPLIFIER Burr-Brown Corporation
INA122 Single Supply/ MicroPower INSTRUMENTATION AMPLIFIER Burr-Brown Corporation
INA125 INSTRUMENTATION AMPLIFIER With Precision Voltage Reference Burr-Brown Corporation

Other Datasheets by Texas Instruments

Part Number Description
INA122 Micropower Instrumentation Amplifier
INA128 Low-Power Instrumentation Amplifiers
INA128-HT Low-Power Instrumentation Amplifiers
INA128U Low-Power Instrumentation Amplifiers
INA129 Low-Power Instrumentation Amplifiers

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
INA126, INA2126 SBOS062C – SEPTEMBER 2000 – REVISED JANUARY 2022 INAx126 MicroPower Instrumentation Amplifiers 1 Features • Low quiescent current: 175 μA/channel • Wide supply range: ±1.
