STM32F401RD - ARM Cortex-M4 32b MCU+FPU

Download the STM32F401RD datasheet PDF. This datasheet also covers the STM32F401CD variant, as both devices belong to the same arm cortex-m4 32b mcu+fpu family and are provided as variant models within a single manufacturer datasheet.

General Description

.

.

.

.

.

.

15 3.1 Arm® Cortex

Key Features

  • Includes ST state-of-the-art patented technology.
  • Core: Arm® 32-bit Cortex®-M4 CPU with FPU, adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from flash memory, frequency up to 84 MHz, memory protection unit, 105 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions.
  • Memories.
  • Up to 512 Kbytes of flash memory.
  • up to 96 Kbytes of SRAM.
  • 512 bytes of OTP memory.
  • Clock, reset, and supply management.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (STM32F401CD-STMicroelectronics.pdf) that lists specifications for multiple related part numbers.

Full PDF Text Transcription for STM32F401RD (Reference)

Note: Below is a high-fidelity text extraction (approx. 800 characters) for STM32F401RD. For precise diagrams, and layout, please refer to the original PDF.

STM32F401xD STM32F401xE ARM Cortex-M4 32b MCU+FPU, 105 DMIPS, 512KB Flash/96KB RAM, 11 TIMs, 1 ADC, 11 comm. interfaces Datasheet - preliminary data Features • Includes S...

View more extracted text
11 comm. interfaces Datasheet - preliminary data Features • Includes ST state-of-the-art patented technology • Core: Arm® 32-bit Cortex®-M4 CPU with FPU, adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from flash memory, frequency up to 84 MHz, memory protection unit, 105 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions • Memories – Up to 512 Kbytes of flash memory – up to 96 Kbytes of SRAM – 512 bytes of OTP memory • Clock, reset, and supply management – 1.7 V to 3.
