High frequency amplifier transistor, RF switching (6V, 50mA)
2SC4774 / 2SC4713K
Features 1) Very low output-on resistance (Ron). 2) Low capacitance. Dimensions (Unit : mm)
2SC4774
2.0 0.3
(3)
0.9 0.2 0.7
1.25
Parameter Collector-base voltage Collector-emitter voltage Emitter-base voltage Collector current Collector power dissipation Junction temperature Storage temperature
Symbol VCBO VCEO VEBO IC PC Tj Tstg
Limits 12 6 3 50 0.2 150 −55 to +150
Unit V V V mA W °C °C
(2)
(1)
2.1
Absolute maximum ratings (Ta=25C)
0.65 0.65 1.3
0.15
Each lead has same dimensions
ROHM : UMT3 EIAJ : SC-70
(1) Emitter (2) Base (3) Collector
2SC4713K
Packaging specifications and hFE
Type Package hFE Marking Code Basic ordering unit (pieces)
FE
2.9
1.1 0.4 0.
2SC4774 Datasheet
