ISL3295E - RS-485/RS-422 Transmitters

Download the ISL3295E datasheet PDF. This datasheet also covers the ISL3293E variant, as both devices belong to the same rs-485/rs-422 transmitters family and are provided as variant models within a single manufacturer datasheet.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (ISL3293E-Renesas.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number ISL3295E
Manufacturer Renesas
File Size 930.00 KB
Description RS-485/RS-422 Transmitters
Datasheet download datasheet ISL3295E Datasheet

Overview

DATASHEET ISL3295E, ISL3298E ±16.5kV ESD Protected, +125°C, 3.0V to 5.5V, SOT-23/TDFN Packaged, Low Power, RS-485/RS-422 Transmitters FN6544 Rev.4.00 Oct 9, 2019 The ISL3295E and ISL3298E are ±16.5kV HBM ESD Protected (7kV IEC61000 contact), 3.0V to 5.5V powered, single transmitters for balanced communication using the RS-485 and RS-422 standards.

These drivers have very low output leakage current (±40µA), so they present less than a “1/8 unit load” to the RS-485 bus.

This allows more than 256 transmitters on the network without violating the RS-485 specification’s 32 unit load maximum, and without using repeaters.

Key Features

  • a logic supply pin (VL) that sets the switching points of the DE and DI inputs to be compatible with a lower supply voltage in mixed voltage systems. For companion single RS-485 receivers in micro packages, please see the ISL3280E, ISL3281E, ISL3282E, ISL3283E, ISL3284E datasheet. Related Literature For a full list of related documents, visit our website.
  • ISL3295E and ISL3298E device pages Features.
  • High ESD protection on RS-485 outputs . . . . ±16.5kV HBM - IEC61000-4-2 conta.
