EMH1 / UMH1N / IMH1A
NPN 100mA 50V Complex Digital Transistors (Bias Resistor Built-in Transistors) Datasheet
Parameter
VCC IC(MAX.)
R1 R2
Tr1 and Tr2
50V 100mA 22kW 22kW
lFeatures 1) Built-In Biasing Resistors, R1 = R2 = 22kW.
2) Two DTC124E chips in one package. 3) Built-in bias resistors enable the configuration of
an inverter circuit without connecting external input resistors (see inner circuit). 4) The bias resistors consist of thin-film resistors with complete isolation to allow negative biasing of the input. They also have the advantage of completely eliminating parasitic effects. 5) Only the on/off conditions need to be set for operation, making the circuit design easy. 6) Lead Free/RoHS Compliant.
