SE555 - Timer

Description

The 555 monolithic timing circuit is a highly stable controller capable of producing accurate time delays, or oscillation.

In the time delay mode of operation, the time is precisely controlled by one external resistor and capacitor.

Features

  • Turn-off time less than 2 µs.
  • Max. operating frequency greater than 500 kHz.
  • Timing from microseconds to hours.
  • Operates in both astable and monostable modes.
  • High output current.
  • Adjustable duty cycle.
  • TTL compatible.
  • Temperature stability of 0.005% per °C.
