MJE13009 - NPN Silicon Power Transistors

onsemi

Key Features

http://onsemi. com.
VCEO(sus) 400 V and 300 V.
Reverse Bias SOA with Inductive Loads @ TC = 100_C.
Inductive Switching Matrix 3 to 12 Amp, 25 and 100_C tc @ 8 A,.
700 V Blocking Capability.
SOA and Switching.

MJE13009 npn silicon power transistors by onsemi - Datasheet Preview

Datasheet Details

Part number	MJE13009
Manufacturer	onsemi
File Size	143.06 KB
Description	NPN Silicon Power Transistors
Datasheet	MJE13009 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
MJE13009	12 AMPERE NPN SILICON POWER TRANSISTOR	Motorola
MJE13009	HIGH VOLTAGE FAST-SWITCHING NPN POWER TRANSISTOR	ST Microelectronics
MJE13009	SWITCHMODE SERIES NPN SWITCHMODE SERIES NPN TRANSISTORS	UTC
MJE13009	NPN Silicon Power Transistors	TGS
MJE13009	Silicon NPN Power Transistors	Inchange Semiconductor

Other Datasheets by onsemi

Part Number	Description
MJE13009G	NPN Silicon Power Transistors
MJE13003	NPN Silicon Power Transistor
MJE13005G	NPN Silicon Power Transistors
MJE13007	Switch-mode NPN Bipolar Power Transistor
MJE13007G	NPN Bipolar Power Transistor
MJE15028	Complementary Silicon Plastic Power Transistor
MJE15029	Complementary Silicon Plastic Power Transistor
MJE15030	Complementary Silicon Plastic Power Transistor
MJE15031	Complementary Silicon Plastic Power Transistor
MJE15032	NPN Power Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

MJE13009 Preferred Device SWITCHMODEt Series NPN Silicon Power Transistors The MJE13009 is designed for high−voltage, high−speed power switching inductive circuits where fall time is critical. They are particularly suited for 115 and 220 V SWITCHMODE applications such as Switching Regulators, Inverters, Motor Controls, Solenoid/Relay drivers and Deflection circuits. Features http://onsemi.
