2SD1615A Datasheet NPN Transistors

Manufacturer: Kexin Semiconductor

📥 Download Datasheet

Overview

SMD Type NPN Transistors 2SD1615A Transistors ■.

Key Features

  • s.
  • Low VCE(sat).
  • Complementary to 2SB1115A 1.70 0.1 0.42 0.1 0.46 0.1.
  • Absolute Maximum Ratings Ta = 25℃ Parameter Collector - Base Voltage Collector - Emitter Voltage Emitter - Base Voltage Collector Current - Continuous Collector Current - Pulse (Note.1) Collector Power Dissipation Junction Temperature Storage Temperature Range Note.1:PW ≤ 10 ms, Duty cycle ≤ 20%. Symbol VCBO VCEO VEBO IC ICP PC TJ Tstg Rating 120 60 6 1 2 2 150 -55 to 150.
  • Electrical Char.
