2SD1368 Datasheet NPN Transistors

Manufacturer: Kexin Semiconductor

Datasheet Details

SMD Type NPN Transistors 2SD1368 Transistors ■.

s.
Low frequency power amplifier.
Complementary to 2SB1002 1.70 0.1 0.42 0.1 0.46 0.1.
Absolute Maximum Ratings Ta = 25℃ Parameter Collector - Base Voltage Collector - Emitter Voltage Emitter - Base Voltage Collector Current - Continuous Collector Current - Pulse (Note.1) Collector Power Dissipation Junction Temperature Storage Temperature Range Note.1:PW ≤ 10 ms, Duty cycle ≤ 20%. Symbol VCBO VCEO VEBO IC ICP PC TJ Tstg Rating 100 50 6 1 1.5 1 150 -55 to 150.
