RT1P141M - Transistor

Download the RT1P141M datasheet PDF. This datasheet also covers the RT1P141x variant, as both devices belong to the same transistor family and are provided as variant models within a single manufacturer datasheet.

Description

RT1P141X is a one chip transistor with built-in bias resistor,NPN type is RT1N141X.

Built-in bias resistor (R1=10kΩ,R2=10kΩ).

Inverted circuit,switching circuit,interface circuit, driver circuit.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (RT1P141x_IsahayaElectronicsCorporation.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number RT1P141M
Manufacturer Isahaya Electronics Corporation
File Size 150.55 KB
Description Transistor
Datasheet download datasheet RT1P141M Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
RT1P137L TRANSISTOR WITH RESISTOR FOR SWITCHING APPLICATION SILICON PNP EPITAXIAL TYPE ETC
RT1P137P SWITCHING SILICON PNP EPITAXIAL TRANSISTOR ETC
RT1P137S RT1P137S ETC
RT1P15BC Transistor Isahaya Electronics
RT1P15BM Transistor Isahaya Electronics

Other Datasheets by Isahaya Electronics Corporation

Part Number Description
RT1P141C Transistor
RT1P141S Transistor
RT1P141T Transistor
RT1P141U Transistor
RT1P141x Transistor

Full PDF Text Transcription

Click to expand full text
www.DataSheet4U.com ＲＴ１Ｐ１４１Ｘ SERIES 〈Transistor〉 Transistor With Resistor For Switching Application Silicon PNP Epitaxial Type DESCRIPTION RT1P141X is a one chip transistor with built-in bias resistor,NPN type is RT1N141X. FEATURE Built-in bias resistor (R1=10kΩ,R2=10kΩ). APPLICATION Inverted circuit,switching circuit,interface circuit, driver circuit. 1.6 1.0 0.5 0.5 0.3 2.9 1.90 0.95 0.95 0.4 OUTLINE DRAWING UNIT：mm RT1P141U RT1P141C 1.6 0.4 0.8 0.4 2.5 0.5 1.5 0.5 ① ②③ ① ②③ 0.7 0.55 0～0.1 0.15 1.1 0.8 0～0.1 0.16 Equivalent circuit R1 B (IN) R2 C (OUT) E (GND) RT1P141S 4.0 0.1 0.45 2.0 1.3 0.65 0.65 0.3 1.2 0.8 0.4 0.4 JEITA：－ JEDEC：－ Terminal Connector ①：Base ②：Emitter ③：Collector RT1P141M 2.1 0.425 1.25 0.
