HT7327-7 - 30V 250mA TinyPower LDO

Download the HT7327-7 datasheet PDF. This datasheet also covers the HT7321-7 variant, as both devices belong to the same 30v 250ma tinypower ldo family and are provided as variant models within a single manufacturer datasheet.

Description

The HT73xx-7 is a low power high voltage series of regulators implemented in CMOS technology which has the advantages of low voltage drop and low quiescent current.

They allow input voltages as high as 30V and are available with several fixed output voltages ranging from 2.1V to 5.0V.

Features

  • Low power consumption.
  • Low voltage drop.
  • Low temperature coefficient.
  • High input voltage.
  • up to 30V.
  • Output voltage accuracy: tolerance ±2%.
  • Over current protection.
  • Over temperature protection.
  • Chip enable/disable function.
  • Package types: 8-pin SOP-EP, SOT89-3 and TO92-3.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (HT7321-7-HoltekSemiconductor.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
HT7005L LCD HYES Optoelectronics
HT7017 High-precision single-phase metering chip HiTrendtech
HT7020 three-port low voltage detector UMW
HT7022 three-port low voltage detector UMW
HT7024 three-port low voltage detector UMW

Other Datasheets by Holtek Semiconductor

Part Number Description
HT7327-1 250mA TinyPower LDO
HT7327-2 30V 250mA TinyPower LDO
HT7327-3 250mA TinyPower LDO
HT7327 Low Power Consumption LDO
HT7321-1 250mA TinyPower LDO

Full PDF Text Transcription

Click to expand full text
HT73xx-7 30V, 250mA TinyPowerTM LDO with Protections Features • Low power consumption • Low voltage drop • Low temperature coefficient • High input voltage – up to 30V • Output voltage accuracy: tolerance ±2% • Over current protection • Over temperature protection • Chip enable/disable function • Package types: 8-pin SOP-EP, SOT89-3 and TO92-3 Applications • Battery-powered equipment • Communication equipment • Audio/Video equipment General Description The HT73xx-7 is a low power high voltage series of regulators implemented in CMOS technology which has the advantages of low voltage drop and low quiescent current. They allow input voltages as high as 30V and are available with several fixed output voltages ranging from 2.1V to 5.0V.
