HT1130 - 4-bit Microcontroller

General Description

The HT1130 is a processor from Holtek s 4-bit stand alone single chip microcontroller range specifically designed for LCD product applications.

Internal timer overflow interrupt External interrupt One level subroutine nesting 8-bit t

Key Features

  • Operating voltage: 2.4V~3.3V.
  • 12 input lines.
  • Four output lines.
  • Five working registers.
  • Sound effect circuit.
  • 4K ´ 8 program ROM.
  • 128 ´ 4 bits data memory RAM size.
  • 32 ´ 4 segment LCD driver.
  • RC oscillator for system clock.
  • Halt feature reduces power consumption General.

📥 Download Datasheet

More Datasheets from Holtek Semiconductor

Part Number Description
HT1015-1 1.5V Low Power LDO
HT1086 1.5A General Purpose LDO
HT1380A Serial Timekeeper Chip
HT1381A Serial Timekeeper Chip
HT1382 I2C/3-Wire Real Time Clock
HT1608 2 x 20 Channel LCD Driver
HT1612 Timer
HT1613C Timer
HT1616C Timer
HT1621G RAM Mapping 32 x 4 LCD Controller

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
HT1130 4-bit Microcontroller Features · Operating voltage: 2.4V~3.3V · 12 input lines · Four output lines · Five working registers · Sound effect circuit · 4K ´ 8 program ROM · 128 ´ 4 bits data memory RAM size · 32 ´ 4 segment LCD driver · RC oscillator for system clock · Halt feature reduces power consumption General Description The HT1130 is a processor from Holtek s 4-bit stand alone single chip microcontroller range specifically designed for LCD product applications.
