FZT589 - PNP MEDIUM POWER TRANSISTOR

Key Features

  • BVCEO > -30V.
  • IC = -1A High Continuous Current.
  • Excellent hFE Characteristics up to -2A.
  • Low Saturation Voltage VCE(sat) < -0.35V @ -1A.
  • Complementary NPN Type: FZT489.
  • Lead-Free Finish; RoHS Compliant (Notes 1 & 2).
  • Halogen and Antimony Free. “Green” Device (Note 3).
  • Qualified to AEC-Q101 Standards for High Reliability A Product Line of Diodes Incorporated Green FZT589 30V PNP MEDIUM POWER.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
FZT549 PNP Transistors Kexin
FZT591 PNP Transistors Kexin
FZT593 PNP Silicon High Voltage Transistor Kexin
FZT1048A NPN Transistors Kexin
FZT2222A SOT223 NPN SILICON PLANAR SWITCHING TRANSISTOR Zetex Semiconductors

Other Datasheets by Diodes Incorporated

Part Number Description
FZT549 PNP MEDIUM POWER TRANSISTOR
FZT558 PNP HIGH VOLTAGE TRANSISTOR
FZT560 PNP HIGH VOLTAGE TRANSISTOR
FZT591 PNP MEDIUM POWER TRANSISTOR
FZT591A PNP MEDIUM POWER TRANSISTOR

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Features  BVCEO > -30V  IC = -1A High Continuous Current  Excellent hFE Characteristics up to -2A  Low Saturation Voltage VCE(sat) < -0.35V @ -1A  Complementary NPN Type: FZT489  Lead-Free Finish; RoHS Compliant (Notes 1 & 2)  Halogen and Antimony Free. “Green” Device (Note 3)  Qualified to AEC-Q101 Standards for High Reliability A Product Line of Diodes Incorporated Green FZT589 30V PNP MEDIUM POWER TRANSISTOR IN SOT223 Mechanical Data  Case: SOT223  Case Material: Molded Plastic. “Green” Molding Compound; UL Flammability Rating 94V-0  Moisture Sensitivity: Level 1 per J-STD-020  Terminals: Finish - Matte Tin Plated Leads. Solderable per MIL-STD-202, Method 208  Weight: 0.
