• Part: PN8055
  • Manufacturer: Chipown
  • Size: 710.00 KB
Download PN8055 Datasheet PDF
PN8055 datasheet preview
PN8055 page 2
Page 2
PN8055 page 3
Page 3

PN8055 Key Features

  • Internal 800V avalanche-rugged smart power MOSFET
  • Internal HV Start-up Circuit
  • Be optimized with 15V output non-isolated
  • Semi enclosed steady output power 3.0W@230VAC
  • Frequency modulation for low EMI
  • Excellent constant voltage regulation and high
  • Excellent Protection Coverage
  • Over Load Protection (OLP)
  • Over Temperature Protection (OTP)
  • Under Voltage Lockout (UVLO)

Related Chipown Datasheets

Part Number Description
PN8054 High-performance non-isolated AC/DC conversion chip
PN8015N Non-isolated Off-line PWM converters
PN8016 Non-isolated Off-line PWM converters
PN8034 High-performance non-isolated AC-DC conversion chip
PN8106 Low Standby-Power Off-Line PWM Converters

PN8055 Description

The PN8055 consists of an integrated Pulse Frequency Modulator (PFM) controller and Internal 800V avalancherugged smart power MOSFET, specifically designed for small power non-isolated switching power supply. PN8055 has internal high voltage start-up circuit and plete intelligent protections including adjustable Over Load Protection (OLP), Under Voltage Lockout (UVLO) and Over Temperature Protection (OTP). Excellent...
