LTC4366 - High Voltage Surge Stopper

📥 Download Datasheet

General Description

The LTC®4366 surge stopper protects loads from high voltage transients.

By controlling the gate of an external N-channel MOSFET, the LTC4366 regulates the output during an overvoltage transient.

The load may remain operational while the overvoltage is dropped across the MOSFET.

Overview

LTC4366 High Voltage Surge Stopper.

Key Features

  • n Rugged Floating Topology n Wide Operating Voltage Range: 9V to >500V n Adjustable Output Clamp Voltage n Controls N-Channel MOSFET n Adjustable Protection Timer n Internal 9-Second Cool-Down Timer n Shutdown IQ < 14µA n 8-Lead TSOT and 3mm × 2mm DFN Packages.
