DS110DF111 - 2-Channel Retimer

Texas Instruments

📥 Download Datasheet

DS110DF111 Datasheet Preview — Preview of DS110DF111 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	DS110DF111
Manufacturer	Texas Instruments
File Size	1.40 MB
Description	2-Channel Retimer
Datasheet	DS110DF111-etcTI.pdf

DS110DF111 Product details

Description

The DS110DF111 is a dual-channel (1-lane bidirectional) retimer with integrated signal conditioning.

Features

1 Pin-Compatible Retimer Family.
DS110DF111 With DFE: 8.5 to 11.3 Gbps.
DS125DF111 With DFE: 9.8 to 12.5 Gbps.
Adaptive CTLE Up to 34 dB Boost at 5.65 GHz.
Self-Tuning 5-Tap DFE.
Raw Equalized and Retimed Data Loopback.
Adjustable Transmit VOD: 600 to 1300 mVp-p.
Settable TX De-Emphasis Driver 0 to.
12 dB.
Low Power Consumption: 200 mW/Channel.
Locks to Half, Quarter, and Eighth Data Rates for Legac.
