AS5115 - Programmable 360-o Magnetic Angle Encoder

General Description

The AS5115 is a contactless rotary encoder sensor for accurate angular measurement over a full turn of 360º and over an extended ambient temperature range of -40ºC to +150ºC.

Key Features

  • Contactless angular position encoding.
  • High precision analog output.
  • Buffered Sine and Cosine signals.
  • SSI Interface.
  • Low power mode.
  • Two programmable output modes: Differential or Single ended.
  • Wide magnetic field input range: 20.
  • 80 mT.
  • Wide temperature range: -40ºC to +150ºC.
  • Fully automotive qualified to AEC-Q100, grade 0.
  • SSOP-16 package 3.

📥 Download Datasheet

Datasheet Details

Part number AS5115
Manufacturer austriamicrosystems AG
File Size 1.08 MB
Description Programmable 360-o Magnetic Angle Encoder
Datasheet download datasheet AS5115 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
AS5116 On-Axis Magnetic Position Sensor ams
AS5130 8-Bit Programmable Magnetic Rotary Encoder ams
AS5132 360 Step (8.5 bit) Programmable High Speed Magnetic Rotary Encoder austriamicrosystems
AS5132 360 Step (8.5 bit) Programmable High Speed Magnetic Rotary Encoder ams
AS5140H 10-Bit 360-o Programmable Magnetic Rotary Encoder ams

Other Datasheets by austriamicrosystems AG

Part Number Description
AS5130 8 Bit Programmable Magnetic Rotary Encoder
AS5134 360 Step Programmable High Speed Magnetic Rotary Encoder
AS5140H 10-Bit 360 Programmable Magnetic Rotary Encoder
AS5145 12-Bit Programmable Magnetic Rotary Encoder
AS5145A 12-Bit Programmable Magnetic Rotary Encoder

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Technical coantmesntAsGtill valid Datasheet AS5115 Programmable 360º Magnetic Angle Encoder with Buffered SINE & COSINE Output Signals 1 General Description The AS5115 is a contactless rotary encoder sensor for accurate angular measurement over a full turn of 360º and over an extended ambient temperature range of -40ºC to +150ºC. Based on an integrated Hall element array, the angular position of a simple two-pole magnet is translated into analog output voltages. The angle information is provided by means of buffered sine and cosine voltages. This approach gives maximum flexibility in system design, as it can be directly integrated into existing architectures and optimized for various applications in terms of speed and accuracy.
