EGP20BH, EGP20AH - SINTERED GLASS PASSIVATED JUNCTION HIGH EFFICIENT RECTIFIER

Zowie Technology

Datasheet Details

Part number	EGP20BH, EGP20AH
Manufacturer	Zowie Technology
File Size	51.00 KB
Description	SINTERED GLASS PASSIVATED JUNCTION HIGH EFFICIENT RECTIFIER
Datasheet	EGP20AH-ZowieTechnology.pdf
Note	This datasheet PDF includes multiple part numbers: EGP20BH, EGP20AH. Please refer to the document for exact specifications by model.

Halogen-free type.
GPRC (Glass Passivated Rectifier Chip) inside.
Glass passivated cavity-free junction.
Superfast recovery time for high efficiency.
Low forward voltage, high current capability.
Low leakage current.
High surge current capability.
High temperature soldering guaranteed: 260oC/10 seconds, 0.375" (9.5mm) lead length, 5lbs. (2.3 kg) tension.
Plastic package has Underwriters Laboratory Flammability Classification 94V-0.
