ZTP7193SI - Synchronous Step-Down DC/DC Converter

ZillTek

📥 Download Datasheet

ZTP7193SI Datasheet Preview — Preview of ZTP7193SI PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	ZTP7193SI
Manufacturer	ZillTek
File Size	0.96 MB
Description	Synchronous Step-Down DC/DC Converter
Datasheet	ZTP7193SI-ZillTek.pdf

ZTP7193SI Product details

Description

The ZTP7193SI is a high-frequency, synchronous, rectified, step-down, switch-mode converter with internal power MOSFETs.

Features

4.75V to 18V input voltage.
Output adjustable from 0.923V to 15V.
Output current up to 3A.
Integrated 105mΩ/85mΩ power MOSFET switches.
Shutdown current 3μA typical.
Efficiency up to 95%.
Fixed frequency 500KHz.
Internal soft start.
Over current protection and Hiccup.
Over temperature protection.
RoHS Compliant and 100% Lead (Pb) Free.
