ZSSC3170 - Automotive Sensor Signal Conditioner

Description

The ZSSC3170 is a CMOS integrated circuit for highly accurate amplification and sensor specific correction of bridge sensor signals.

Featuring a maximum analog gain of 420, as well as extended offset compensation capabilities, the ZSSC3170 is adjustable to nearly all resistive bridge sensor types.

📥 Download Datasheet

Datasheet Details

Part number ZSSC3170
Manufacturer Zentrum Mikroelektronik Dresden
File Size 710.76 KB
Description Automotive Sensor Signal Conditioner
Datasheet download datasheet ZSSC3170 Datasheet
