DW8-24S24
features
, the product can be used where the wider input, regulated output and isolation needed.
ELECTRICAL SPECIFICATIONS
All specifications tested typically @ 25°C, humidity<75%, nominal input and rated output unless otherwise noted.
OUTPUT SPECIFICATIONS
Items: Output accuracy: Line regulation:
Load regulation:
Ripple and noise: Temperature drift: Dynamic Respond Speed Switching frequency Over load protection Start- up Time
Testing condition From 0% to100% load
Full load From 0% to full load (20MHz Bandwidth)
25% negative Load to full load
% of FL at nominal input
Min Typ
Max
Main Output: 1.0%max, Secondary: 1.5%max
Main Output: 0.2%max, Secondary: 0.5%max Main output: 0.5%max Second output: 1.0%max 100m Vp-p
0.02 %/°C
150us
300KHz
500ms
INPUT SPECIFICATIONS
Items:
Input voltage range
Input filter Linearity High Speed
Leakage current Capacitance
Testing condition 5VDC 12VDC 24VDC 48VDC
From low to high
Min 4.5 9 18 36 Pi
Typ 9 18 36 72
1m A 80 p F
Max 9 20 40...
