SS120 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS

This page provides the datasheet information for the SS120, a member of the SS12 1.0AMP SCHOTTKY BARRIER RECTIFIERS family.

Datasheet Summary

Features

  • Ideal for surface mounted.

📥 Download Datasheet

Datasheet preview – SS120

Datasheet Details

Part number SS120
Manufacturer WILLAS
File Size 311.90 KB
Description 1.0AMP SCHOTTKY BARRIER RECTIFIERS
Datasheet download datasheet SS120 Datasheet
Additional preview pages of the SS120 datasheet.

📁 Similar Datasheet

  • SS1200 - SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS (GME)
  • SS1200 - 1.0A HIGH VOLTAGE SURFACE MOUNT SCHOTTKY BARRIER DIODE (WON-TOP)
  • SS1200-L - (SS1150-L / SS1200-L) 1 Amp Schottky Rectifier (Micro Commercial Components)
  • SS1200F - Schottky Barrier Rectifiers (GME)
  • SS1200FA - SURFACE MOUNT SCHOTTKY BARRIER RECTIFIERS (GME)
  • SS120A - Surface Mount Schottky Rectifier (Yangjie)
  • SS120A - Schottky Barrier Rectifier (Semiware)
  • SS120A - Surface Mount Schottky Rectifier (DOWOSEMI)
  • SS120AF - 1.0Amp Surface Mount Schottky Barrier Rectifiers (ZRE)
  • SS120D - Surface Mount Schottky Barrier Diodes (SemiWell)
Other Datasheets by WILLAS
  • SS12 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS110 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS115 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS13 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS14 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS15 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS16 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS
  • SS18 - 1.0AMP SCHOTTKY BARRIER RECTIFIERS

Full PDF Text Transcription

Click to expand full text
WILLAS 1.0AMP SCHOTTKY BARRIER RECTIFIERS SMA PACKAGE SS12 THRU SS120 FEATURES * Ideal for surface mounted applications * Low leakage current * Metallurgically bonded construction * High reliability * RoHS product for packing code suffix "G" Halogen free product for packing code suffix "H" MECHANICAL DATA * Case: Molded plastic * Epoxy: UL 94V-O rate flame retardant * Mounting position: Any * Weight: 0.066 gram .067(1.70) .051(1.29) .181(4.60) .160(4.06) .110(2.79) .086(2.18) .091(2.31) .067(1.70) .059(1.50) .035(0.89) .012(.305) .006(.152) .008 Max. (.203) .208(5.28) .188(4.80) Dimensions in inches and (millimeters) MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS Ratings at 25℃ ambient temperature unless otherwise specified.
