SM8S20AT, SM8S10AT - TVS

Name: SM8S20AT
SKU: SM8S20AT-967229

Vishay

The SM8S20AT by Vishay is a TVS. Below is the official datasheet preview.

Datasheet Details

Part number	SM8S20AT, SM8S10AT
Manufacturer	Vishay
File Size	102.02 KB
Description	TVS
Datasheet	SM8S10AT-Vishay.pdf
Note	This datasheet PDF includes multiple part numbers: SM8S20AT, SM8S10AT. Please refer to the document for exact specifications by model.
Additional preview pages of the SM8S20AT datasheet.

Junction passivation optimized design passivated anisotropic rectifier technology.
TJ = 175 °C capability suitable for high reliability and automotive requirement.
Available in uni-directional polarity only.
Low leakage current.
Low forward voltage drop.
High surge capability.
Meets ISO7637-2 surge specification (varied by test condition).
Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C.
AEC-Q101 qualif.
