DFA04S - Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifier

Vishay Siliconix

The DFA04S by Vishay Siliconix is a Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifier. Below is the official datasheet preview.

📥 Download Datasheet

DFA04S Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifier by Vishay Siliconix - Datasheet Preview — Official preview page of the **DFA04S** Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifier datasheet (Vishay Siliconix).

Datasheet Details

Part number	DFA04S
Manufacturer	Vishay Siliconix
File Size	27.62 KB
Description	Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifier
Datasheet	DFA04S_VishaySiliconix.pdf
Additional preview pages of the DFA04S datasheet.

DFA04S Product details

Features

Plastic package has Underwriters Laboratory Flammability Classification 94V-0.
This series is UL listed under Recognized Component Index, file number E54214.
Glass passivated chip junctions.
High surge overload rating of 30 Amperes peak.
Ideal for printed circuit boards.
High temperature soldering guaranteed: 260°C/10 seconds at 5 lbs. (2.3kg) tension (TA = 25°C unless otherwise noted) Case: Molded plastic body over passivated junctions Ter.
