Standard Power Integrated Module
www.datasheet4u.com
flowPIM® 1
Features/ Eigenschaften
3 phases Input Rectifier 3 phases inverter trench IGBT + FRED NTC
Copyright by Vincotech
Revision:1
V23990-P48X-A
flowPIM® 1
module types / Produkttypen
www.datasheet4u.com
part – number V23990P481- A-PM P482- A-PM P483- A-PM P484- A-PM P485- A-PM P486- A-PM P487- A-PM P488- A-PM P480- A-PM
Voltage 600V 600V 600V 600V 600V 600V 1200V 1200V 1200V
current 5A 8A 10A 15A 20A 30A 10A 15A 25A
Schematics/ Schaltpläne
Type A: with BRC, 3~ rectifier
On request partially assembled versions can be offered, e.g. without BRC.
Copyright by Vincotech
Revision:1
V23990-P48X-A
flowPIM® 1
Outline / Pinout
www.datasheet4u.com
Toleranz der Pinpositionen: 0.5 mm am Pinende Tolerance of pin positions: 0.
V23990-P487-A-PM Datasheet
